    JL350J-1A 220V AC 30liter/min external control industrial material chemical feeding hose peristaltic pump

    Ask Lasest Price
    Brand Name : Huiyu fluid
    Model Number : JL350J-1A
    Certification : ce
    Supply Ability : 100 Set/Sets per Week
    Price : $1,660.00 - $2,550.00/sets
    • Product Details
    • Company Profile

    JL350J-1A 220V AC 30liter/min external control industrial material chemical feeding hose peristaltic pump


    Product Description

    industrial peristaltic hose pump

    JL350J-1A 220V AC 30liter/min external control industrial material chemical feeding hose peristaltic pump

    Introduction
    JL350-1A peristaltic pump is ideal for high flow rates fluids transfer, driven by the AC motor and the frequency converter control the speed.The pump delivers flow rates is less than 35 L/min. Through the transparent front cover, the running status of the pump head is visible. The speed, running direction and run/stop of the pump are controlled manually by membrane Keypad or automatically by external control interface. Its operation is simple and reliable.
    Technical parameters
    -Speed: 30 to 350 rpm, reversible
    - Max flow rate:35liter/min
    -Speed precision: 0.6 rpm
    -Speed control: rotary encoder switch, acceptable external control and communication control
    -Display: LED display
    -Speed control signal input: 0-5V,0-10V,4-20mA
    -Start and stop control signal input: switching control
    -Direction control signal input: switching control
    -Communication interface: RS485 and RS232
    -Dimensions (L × W × H): 417×401×321 (mm)
    -Power supply: AC 220V±20%
    -Power consumption: < 400 W
    -Operating condition: Temperature 0 to 40°C,
    -Relative humidity < 80%
    -IP rating: IP55
    -Pump weight: 32 kg
    Functions and features
    - High-power pumps, and the maximum flow rates can reach 35L/min
    - The structure of concave working surface and convex roller realize the tubing self-position function. It reduces abrasion and prolongs tubing life.
    - Variable frequency speed control to AC motor with creeper gear
    - Adjustable occlusion
    - Strong drive
    - Pump head operation is visible through transparent front cover

    Technical Data Sheet
    DrivePump headAvailable tubingflow rate range (ml/min)weight(kg)
    JL350J-1AKZ48/6388#1.3-1532
    92#3-35

    Flow rate chart

    JL350J-1A 220V AC 30liter/min external control industrial material chemical feeding hose peristaltic pump

    Mounting drawing

    JL350J-1A 220V AC 30liter/min external control industrial material chemical feeding hose peristaltic pump

    Tubing loading

    JL350J-1A 220V AC 30liter/min external control industrial material chemical feeding hose peristaltic pump

    OEM option

    JL350J-1A 220V AC 30liter/min external control industrial material chemical feeding hose peristaltic pump

    Accessories

    JL350J-1A 220V AC 30liter/min external control industrial material chemical feeding hose peristaltic pump

    CE certificate

    JL350J-1A 220V AC 30liter/min external control industrial material chemical feeding hose peristaltic pump

    JL350J-1A 220V AC 30liter/min external control industrial material chemical feeding hose peristaltic pump
